Home GRT8-A1 16A 1/2SPDT AC230V/AC/DC 12-240V ON Delay Timer Relay

Description

The GRT8-A 16A 1/2SPDT AC230V/AC/DC 12-240V ON Delay Timer Relay provides precise timing control with a user-friendly design. Its Delay OFF functionality ensures accurate and consistent performance in various applications.

A 12-240V ON Delay Timer Relay is a versatile device used in various applications for controlling electrical circuits with a delay. Here are some key features and benefits:

Key Features

Voltage Range: Operates on a wide voltage range (12V to 240V), making it suitable for different systems.
Delay Time Settings: Adjustable delay settings, typically ranging from seconds to several minutes, allowing for customization based on specific needs.
Compact Design: Often designed to fit standard relay sockets, saving space in control panels.
LED Indicator: Many models come with an LED indicator to show the status of the relay and whether the delay is active.
Multiple Contact Configurations: Available in various configurations (SPDT, DPDT) for flexibility in circuit design.
High Reliability: Built for durability and consistent performance in various operating conditions.
Easy Installation: Simple wiring and setup process, often with clear instructions.

Benefits

Energy Savings: Reduces energy consumption by preventing equipment from running unnecessarily when not needed.
Enhanced Control: Provides precise control over equipment operation, improving efficiency and performance.
Protection of Equipment: Helps prevent damage to motors and other devices by managing startup times and reducing inrush currents.
Safety: Incorporating a delay can prevent hazardous situations in applications where immediate operation could pose risks.
Flexibility: Suitable for a wide range of applications, including HVAC systems, lighting control, and industrial automation.
User-Friendly: Adjustable settings make it easy for users to tailor the relay's operation to their specific requirements.
Cost-Effective Solution: Reduces operational costs by optimizing equipment usage and extending the lifespan of components.

Overall, a 12-240V ON Delay Timer Relay offers a practical solution for managing electrical circuits efficiently and safely, making it a valuable component in various applications.

Technical Specifications:

Model: GRT8-A1/B1
Function: Delay NO
Supply Voltage: AC/DC 12-240V(50-60Hz)
Time Range: 0.1s-10days, ON, OFF
Contacts: 1XSPDT, 2XSPDT
Mounting: Din rail EN/IEC 60715
Output Indication: Red LED
Supply Indication: Green LED
Dimensions: 90×18×64mm
Standards: EN 61812-1, IEC6947-5-1

Applications:

HVAC Systems
Lighting Control
Industrial Automation
Agricultural Equipment
Automotive Applications
Home Automation
Commercial Equipment
Power Management
Marine Applications
Testing and Prototyping

Order Your GRT8-A 16A 12-240V ON Delay Timer Relay Today!

Experience the reliability and precision of the GRT8-A1/B1 12-240V ON Delay Timer Relay

How to set time 12-240V ON Delay Timer Relay

How to setting time:

Knob 1: delay gear setting, “s” for second, “m” for minute, “h” for hour, “d” for day, “ON” for relay action (15-18/25-28 closed),
“OFF” for relay open (15-18/25-28 open)

Knob 2: fine adjustment of delay time, 10% ~ 100% adjustable.

Function Diagram:

Dimension:

Technical Data

Function	A:delay ON: B:delay OFF
Supply terminals	A1-A2
Voltage range	AC/DC 12-240V(50-60Hz
Burden	AC 0.09-3VA/DC 0.05-1.7W
Voltage range	AC 230V(50-60Hz)
Power input	AC max.6VA/1.9W
Supply voltage tolerance	-15%+10%
Supply indication	green LED
Time ranges	0.1s-10days, ON, OFF
Time setting	potentionmeter
Time deviation	10%-mechanical setting.
Repeat accuracy	0.2%-set value stability
Temperature coefficient	0.05%/°C,at=20°C(0.05%°F, at 68°F)
Output	1XSPDT, 2XSPDT, 1xSPDT)+1XSPOT)
Current rating	1×16A(AC1), 2X16A(AC1)
Switching voltage	250VAC/24VDC
Min. breaking capacity DC	500mW
Output	red LED
Mechanical life	1×107
Electrical life(AC1)	1×105
Reset time	max.200ms
Operating temperature	-20°C to +55°C (-4°F to 131°F)
Storage temperature	-35°C to +75°C (-22°F to 158°F)
Mounting/DIN rail	Din rail EN/IEC 60715
Protection degree	IP40 for front panel/IP20 terminals
Operating position	Any
Overvoltage cathegory	III.
Pollution degree	2
Max.cable size(mm)	solid wire max. 1X2.5or 2x1.5/with sleeve max.1×2.5(AWG 12)
Dimensions	90×18×64mm
Weight	1xSPDT:W240-60g,A230-59g
Standards	EN 61812-1, IEC6947-5-1
